Application of High Voltage Power Supply in X-ray Instrument Field - Medical Field

X-ray technology has been widely applied in fields such as medicine, industry, and scientific research. X-ray equipment is an indispensable tool in clinical diagnosis and treatment in the medical field, and high-voltage power supply is one of the core components of X-ray equipment, playing a crucial role in generating and maintaining X-rays.

High voltage power supply is a key component in X-ray equipment, whose main function is to provide stable, high-energy electron beams and generate the high voltage electricity required to output X-rays. The electron beam is accelerated under the action of a high-voltage power supply, and then X-rays are generated through the target material. When a high-voltage power supply is in operation, it first converts alternating current into direct current, and then converts the direct current into high-frequency alternating current through an inverter. Finally, the high-voltage transformer is used to boost the voltage and generate the high voltage required for X-rays. The high-voltage power supply must be able to provide sufficient voltage and current to ensure the generation of sufficient X-rays to penetrate objects and produce high-quality images.

The quality and stability of high-voltage power supply will directly affect the quality of X-ray imaging. Unstable power supply may cause image blurring, insufficient contrast, or artifacts, which can reduce the accuracy of diagnosis and lead to misdiagnosis. In addition, high-voltage power supplies must comply with the safety standards of medical equipment to ensure the safety of patients and medical staff. Our high-voltage power supply has the characteristics of high output voltage, high stability, and high reliability, ensuring that it meets the requirements of X-ray equipment.

1. High output voltage: The high-voltage power supply can output voltages up to tens or even hundreds of kilovolts, providing necessary radiation sources for X-ray equipment.

2. High stability: The high-voltage power supply adopts advanced voltage stabilization technology to ensure the stability of the output voltage, thereby improving the measurement accuracy of X-ray equipment.

3. High reliability, the high-voltage power supply adopts a redundant design to ensure that the equipment can automatically switch in case of abnormal situations, ensuring the normal operation of the equipment and ensuring safety and reliability.
